ISO ESFR Chrome on Glass
images
ISO ESFR Chrome on Glass
images
ISO ESFR Chrome on Glass
images
ISO ESFR Chrome on Glass
$770.00 – $1,300.00
This chart is produced with the highest precision process we have available.  For more detailed information on the various processes by which we create our targets, please take a look at our Transmissive Chart Quality Comparison. For ease of placement and removal, options include an acrylic frame sized for Imatest LED Lightboxes size B through D and Light Panels size A through D. Chrome on Glass charts are uni-tone, have 10:1 contrast,
Description
| Plate Size | Thickness | Active Area* | SKU |
| 2.54cm x 7.62cm (1″ x 3″) | 1.6mm (0.06″) | 5 chart patterns | ESFRCG-1×3-Multi |
| 5.08cm (2″) | 1.6mm (0.06″) | 29.57mm x 19.3mm | ESFRCG-2-Enhanced |
| 5.08cm (2″) | 1.6mm (0.06″) | 29.76mm x 16.28mm | ESFRCG-2-Extended |
| 10.16cm (4″) | 1.6mm (0.06″) | 78.34mm x 51.14mm | ESFRCG-4-Enhanced |
| 10.16cm (4″) | 1.6mm (0.06″) | 78.85mm x 43.13mm | ESFRCG-4-Extended |
| 2.54cm x 7.62cm (1″ x 3″) | 1.6mm (0.06″) | 5 chart patterns | ESFRCG-1×3-Multi-2023 |
| 5.08cm (2″) | 1.6mm (0.06″) | 29.73mm x 16.73mm | ESFRCG-2-Extended-2023 |
| 10.16cm (4″) | 1.6mm (0.06″) | 78.77mm x 44.31mm | ESFRCG-4-Extended-2023 |
*The active area is measured to the interior of the black borders of the pattern.
| The 1 x 3″ Multi Slide includes five patterns: | |
| 2017 ESFR | 2023 ESFR |
| 21.26mm x 11.63mm (084″ x 0.46″) | 21.24mm x 11.95mm (0.84″ x 0.47″) |
| 11.46mm x 6.27mm (0.45″ x 0.25″) | 11.45mm x 6.44mm (0.45″ x 0.25″) |
| 7.64mm x 4.18mm (0.3″ x 0.17″) | 7.63mm x 4.29mm (0.3″ x 0.17″) |
| 5.09mm x 2.79mm (0.2″ x 0.11″) | 5.09mm x 2.86mm (0.2″ x 0.11″) |
| 3.39mm x 1.86mm (0.13″ x 0.07″) | 3.39mm x 1.91mm (0.13″ x 0.08″) |
