This page provides examples of stray light manifesting itself in images from real cameras.


Image Notes
Ghost reflections, color shifts, and specular highlights caused by contamination on the windshield
Ring pattern from the sun
Reflection off an external baffle (phone case)
Ghost reflections
Diffraction spikes, veiling glare (loss of contrast), and a ghost reflection (green feature to lower left of sun)
Petal flare (red flower shaped stray light)
Veiling glare near sun, red petal flare to lower left of sun, green flare in lower right corner of image
